The charcoal dryer machine is mainly used to dry all kinds of charcoal briquettes, such as shisha charcoal, hookah charcoal, barbecue charcoal briquettes, etc. This industrial charcoal briquettes drying machine can adopt a variety of heating methods and is very convenient to use. In addition to drying charcoal, it can also be used to dry all kinds of fruits, vegetables, meat, etc.
Hookah charcoal dryer or bbq charcoal dryer is the ideal equipment for the quick drying of the shisha/hookah charcoal or barbecue charcoal briquettes, which is also named charcoal drying box or charcoal dryer room. The charcoal dryer machine is very suitable for commercial charcoal production lines to make charcoal in large quantities.
Besides, this charcoal drying machine is made of 304 stainless steel so that it can also be used to dry all kinds of the fruits and vegetables like date, pepper, carrot, bean, garlic, longan, agaric, hawthorn, mushroom, and so on.
Mesh belt dryer is a continuous drying equipment for batch production. It is used for drying flake, strip and granular materials with good air permeability. It is especially suitable for materials whose temperature is not allowed to be high; this series of dryers have the advantages of fast drying speed, high evaporation intensity, and good product quality. For paste materials such as dehydrated filter cakes, they need to be granulated or made into strips before drying.
Materials are uniformly put on the mesh-belt by the feeder. The mesh-belt uses generally 12-60 mesh stainless steel wire net and it is drawn and moved inside the drier by a transmission device. The drier is composed of several units. For each unit, the hot air is circulated separately. Some exhausted gas is discharged with a special moisture elimination blower. The waste gas is controlled through an adjustment valve. The hot air passes through the mesh-belt covered with the material from the top to the bottom or from the bottom to the top and this will complete the heat and mass transfer process. This process will bring the material water away. The mesh-belt moves slowly, running speed can be freely adjusted according to the material temperature. The final products after drying will fall into the material collector continuously. The top and low circulation units can be freely equipped according to the users’ demand. The unit number can be selected according to the demand.
DW series multi-layer belt dryer is a continuous drying equipment for batch production. It is suitable for large-scale production of difficult-to-dry materials with low drying rate. The equipment has compact structure, small floor area, simple operation, convenient maintenance and stable operation.
Model | DW-5-1.2-8 | DW-5-1.2-10 | DW-5-1.6-8 | DW-5-1.6-10 | DW-5-2-8 | DW-5-2-10 | |
Width of belt(m) | 1.2 | 1.6 | 2 | ||||
Length of dry section(m) | 8 | 10 | 8 | 10 | 8 | 10 | |
Thickness of raw material spreading(mm) | 10-50 | ||||||
Operation temperature(℃) | 50-120 | ||||||
Steam pressure(MPa) | 0.2-0.5 | ||||||
Steam consumption(kg/h) | ≤2Kg steam/evaporating 1kg water (for vegetables and herbal pieces) | ||||||
Drying capacity(kg water/h) | 100-250 | 120-350 | 110-320 | 140-320 | 150-450 | 200-550 | |
Total power(kw) | 21.2 | 22.7 | |||||
Overall dimensions | L(m) | 11 | 12.5 | 11 | 12.5 | 11 | 12.5 |
W(m) | 1.6 | 1.6 | 2.0 | 2.0 | 2.4 | 2.4 | |
H(m) | 2.7 | 2.7 | 2.7 | 2.7 | 2.7 | 2.7 | |
Weight(kg) | 3800 | 4780 | 4400 | 5550 | 5350 | 6800 | |
Note: Multi-layer mesh belt dryers are available in 3, 5, 7 and 9 layers. |
